Glass Glass Module DDM(P)320

  • Monocrystalline Cell: 120 Cells
  • Maximum Efficiency: 19.1%
  • Power Output Range: 315-320Wp
  • Maximum System Voltage: DC1500
  • Module Dimensions 2384×1303×35mm
  • Packing: 33pcs/pallet

Product Introduction

Product Advantage

– Higher efficiency Mono Perc Cell Technology

– Low current density technology to decrease the internal power consumption effectively

– MBB and HC technology to reduce the negative affection to yield caused by micro crack and shadow

– High power output lead to lower BOS cost



Product Parameters

158.75MM PERC Mono Bifacial Double Glass Module DDM(P)315~320
Electrical performance parameters (front)
Test condition:irradiance=(1+0.1BiFi)1000W/㎡,ambient temperature=25℃,AM=1.5
Type DDM(P)315 DDM(P)320
Maximum power(Pm/Wp) 315 320
Maximum power voltage(Vmp/V) 40.2 40.4
Short circuit current(Isc/A) 9.91 10.02
Peak power voltage(Vmp/V) 33.3 33.4
Peak power current(Imp/A) 9.46 9.58
Module efficient(%) 18.8 19.1
Electrical performance parameters (back)
Type DDM(P)315 DDM(P)320
Maximum power(Pm/Wp) 237 241
Maximum power voltage(Vmp/V) 39.9 40.1
Short circuit current(Isc/A) 7.58 7.64
Peak power voltage(Vmp/V) 34.2 34.3
Peak power current(Imp/A) 6.95 7.03
Module efficient(%) 14.1 14.4
Different back power gains (take 320W as an example)
Power gain 5% 10% 15% 25%
Maximum power(Pm/Wp) 336 352 368 400
Maximum power voltage(Vmp/V) 40.4 40.4 40.4 40.4
Short circuit current(Isc/A) 10.66 11.17 11.68 12.69
Peak power voltage(Vmp/V) 33.4 33.4 33.4 33.4
Peak power current(Imp/A) 10.06 10.54 11.02 11.98
Mechanical parameters
Cell Nos & array 60(6*10)
Number of diodes 3
Junction box/Connector IP68, split junction box
Cable 4mm2, 300mm wire length, the length can be customized
Module Wight (kg) 30
Module dimension (L*W*H)(mm) 1676*1002*7.5 (including junction box thickness 25)
Packing 33pcs/pallet
Temperature Coefficient
Temperature coefficient of Isc +0.05%/℃
Temperature coefficient of Voc -0.29%/℃
Temperature coefficient of Pm -0.39%/℃
Quality parameters
Module working temperature range (℃) -40~+85
Power tolerance(W) 0~+5
Maximum system voltage(V) DC1500
System maximum protection current(A) 20
Module working temperature range (℃) 45±2℃
Front/rear static loads(Pa) 5400/2400
Two-sided factor ≥75%

Product Certification
