Poly Bifacial Laminated Glass RXJJ-MDN210

  • Maximum power(w): 210w
  • Module Efficiency: 13.6%
  • Power Output Range: 210Wp
  • Module Weight (kg): 40kg
  • Module Dimensions: 1460*1060*11mm
  • Wind resistance: 2.4kN/m2

Product Introduction







Product Advantage

Product Parameters

Product name Polycrystalline Silicon Laminated Glass Module
Type RXJJ-MDN210
Electrical parameters Maximum power (Pm/Wp)* 210
Power tolerance (%) ±5
Maximum power voltage (Vmp/V)* 24.78
Maximum power voltage ( Imp/A)* 8.48
Open circuit voltage (Voc/V)* 30
Short circuit current (Isc/A)* 9.35
Module efficiency ηc(%)* 13.6
Maximum system voltage(V) 1500
Working temperature(℃) -40~85
Temperature coefficient of Pm -0.41%/℃
Temperature coefficient of Voc -0.31%/℃
Temperature coefficient of Isc +0.05%/℃
Mechanical parameters Fault structure(mm) 5 Low iron tempered glass+0.76PVB+polycrystalline silicon cell+0.76PVB+5 tempered glass (3.2+3.2 glass can also be used, the thickness is reduced and the weight is reduced)
Cable 4mm2/900mm
Module dimension (L*W*H)(mm) 1460mm*1060mm*11mm
Module Weight (kg) 40kg
Wind resistance 2.4kN/m2

Product Certification
