Poly Hollow Glass RXZK-MDN210

Consult online

Product Introduction

BIPV SOLAR MODULE

BIPV SOLAR MODULE

BIPV SOLAR MODULE

BIPV SOLAR MODULE

BIPV SOLAR MODULE

Type		RXZK-MDN210
Electrical parameters	Maximum power (Pm/Wp)*	210
	Power tolerance (%)	±5
	Maximum power voltage (Vmp/V)*	24.78
	Maximum power voltage ( Imp/A)*	8.48
	Open circuit voltage (Voc/V)*	30
	Short circuit current (Isc/A)*	9.35
	Module efficiency ηc（%）*	13.6
	Maximum system voltage（V）	1500
	Working temperature（℃）	-40～85
	Temperature coefficient of Pm	-0.41%/℃
	Temperature coefficient of Voc	-0.31%/℃
	Temperature coefficient of Isc	+0.05%/℃
Mechanical parameters	Fault structure（mm）	5 Low iron tempered glass+0.76PVB+polysilicon cell+0.76PVB+5 tempered glass+9A+5 tempered glass
	Heat transfer coefficient	3.0W/m²K
	Cable	4mm²/900mm
	Module dimension (LWH)(mm)	1460mm1060mm26mm
	Module Weight (kg)	60kg
	Wind resistance	2.4kN/m²

Utility
It is a photovoltaic power generation facility that is constructed and operated at or near the user's site, and is characterized by self-consumption on the user's side, excess power being connected to the Internet, and balanced adjustment in the distribution network system.
View More 
Commercial & Industrial
The advantages of installing a solar power generation system for industrial and commercial users include: large industrial and commercial electricity consumption, high electricity price, large proportion of self-generated and self-consumption, short payback period, and high yield;
View More 
Residential
Small home solar power system is composed of solar module, solar controller, battery (group). If the output power is AC 220V or 110V, an inverter is also required.
View More 
